SunnySky X Series X3530 V3 Brushless Motor
SunnySky X Series X3530 V3 Brushless Motor
Regular price
$74.99
Regular price
Sale price
$74.99
Quantity
Couldn't load pickup availability
The SunnySky X Series V3 X3530 V3 445KV Brushless Motor is engineered for high-performance RC aircraft enthusiasts. With a stator diameter of 35mm and a stator thickness of 30mm, this motor delivers a maximum continuous power of 2100W, ensuring robust and efficient performance for various flight applications. Its 14-pole design and 445KV rating make it ideal for pilots seeking both power and precision.
KV560
| Stator Diameter | 35mm | Rotor Diameter | 42.5mm |
|---|---|---|---|
| Stator Thickness | 20mm | Body Length | 45mm |
| No.of Stator Slots | 12 | Max Lipo Cell | 6S |
| No.of Rotor Poles | 14 | ESC | 60-80A |
| Motor Kv | 560 | Recommended Prop(inch) | APC12*8/APC12*6/APC13*6.5/APC13*8/APC14*7 |
| No-load current | 1.1A/10V | Weight for aerobatics airplane | 2500g (6S APC13*6.5\APC13*8) |
| Motor Resistance | 23mΩ | Weight for 3D airplane | 2200g (6S APC13*6.5\APC13*8) |
| Max Continuous Current | 80A/30s | ||
| Max Continuous Power | 2000W | ||
| Weight | 219g |
