SunnySky X Series X2814-1400kv V3 Brushless Motor
SunnySky X Series X2814-1400kv V3 Brushless Motor
Couldn't load pickup availability
The SunnySky X Series V3 X2814 1400KV Brushless Motor is engineered for RC enthusiasts seeking high performance and reliability. With a stator diameter of 28mm and a thickness of 14mm, this motor delivers a maximum continuous power of 1,180W, making it ideal for aerobatic airplanes weighing between 1,000g to 1,400g.
Its robust construction features a CNC-machined 6061-T6 aviation aluminum alloy case, ensuring durability and efficient heat dissipation. The motor is equipped with high-quality Japanese NMB bearings for smooth and quiet operation, and hand-wound coils for enhanced performance. Designed for 3-4S LiPo batteries, it is recommended to pair this motor with an 80A ESC and propellers such as APC 8x6 or APC 9x6.
KV1400
| Stator Diameter | 28mm | Rotor Diameter | 35mm |
|---|---|---|---|
| Stator Thickness | 14mm | Body Length | 36mm |
| No.of Stator Slots | 12 | Max Lipo Cell | 3-4S |
| No.of Rotor Poles | 14 | ESC | 80A |
| Motor Kv | 1400 | Recommended Prop(inch) | APC8060/APC9060 |
| No-load current | 2.3A/10V | Weight for aerobatics airplane | 1000g-1400g (4S APC9060\APC8060) |
| Motor Resistance | 15.9mΩ | ||
| Max Continuous Current | 80A/30s | ||
| Max Continuous Power | 1180W | ||
| Weight | 109g |
