SunnySky X Series X2305-1850v V3 Brushless Motors
SunnySky X Series X2305-1850v V3 Brushless Motors
Regular price
$18.00
Regular price
Sale price
$18.00
Quantity
Couldn't load pickup availability
The SunnySky X Series V3 X2305 Brushless Motor 1850KV is a high-performance motor designed for RC planes, drones, and other unmanned aerial vehicles (UAVs). Its advanced engineering ensures efficient power delivery, making it an ideal choice for hobbyists and professionals seeking reliable and robust propulsion systems.
Key Features:
- High Efficiency: The 1850KV rating provides optimal thrust and speed for various aerial applications.
- Lightweight Design: Weighing just 25 grams, it minimizes the overall weight of your aircraft, enhancing flight performance.
- Durable Construction: Built with quality materials to withstand the demands of regular use in RC planes and drones.
KV1850
| No.of Stator Slots | 12 | Rotor Diameter | 28mm |
|---|---|---|---|
| No.of Rotor Poles | 14 | Shaft Diameter | 3mm |
| Motor Kv | 1850 | Body Length(Without Shaft) | 20.5mm |
| No-load current | 0.8A/10V | Body Length | 23.6mm |
| Motor Resistance | 64.5mΩ | Max Lipo Cell | 2-3S |
| Max Continuous Current | 25A/30s | ESC | 20-25A |
| Max Continuous Power | 210W | Recommended Prop(inch) | GWS8043/GWS9047/GWS9050 |
| Weight | 25g |
